Bowers Wilkins 603 S3 Kule Tipi Hoparlör

Ürün Özellikleri

Size & weight

Net weight 27.5kg (60.6 lb)

Dimensions

Height: 985 mm (38.8 in) cabinet only

1,020 mm (40.2 in) including plinth

Width: 190 mm (7.5 in) cabinet only

260 mm (10.2 in) including plinth

Depth: 340 mm (13.4 in) cabinet only

368 mm (14.5 in) including grille and terminals

402 mm (15.8 in) including plinth

Technical details

Drive units

1x ø25mm (1 in) Titanium Dome high-frequency

1x ø150mm (6 in) Continuum cone FST midrange

2x ø165mm (6.5 in) Paper bass cone

Frequency range -6dB 29Hz - 33kHz

Harmonic distortion 2nd and 3rd harmonics (90dB, 1m on axis)

<1% 100Hz - 22kHz

<0.5% 350Hz - 12kHz

Nominal impedance 8Ω (minimum 3.0Ω)

Recommended amplifier power 30W - 200W into 8Ω on unclipped programme

Technical features

Decoupled Double Dome Titanium tweeter

Continuum™ cone FST™ midrange

Paper bass cones

Flowport™

Description

3-way vented-box system

Max recommended cable impedance 0.1Ω

Frequency response (+/-3dB from reference axis) 46Hz - 28kHz ±3dB

Sensitivity (on axis at 2.83Vrms at 1m) 90dB
